Frana pneumatica ghidaj liniar Seria LBPS
- Produse originale Zimmer Group GmbH - Quality Made in Germany!
- Independent de fabricantul de bare de ghidaj liniar
- Energizare pentru închidere (NC)
- Deschidere prin presiunea aer comprimat
- Formă de construcțiva compacta - ingustă și joasă prin utilizarea pistonului în formă de U
- Fexibilitate maxim prin conexiune suplimentară pe partea de jos pentru aer comprimat
- Verificare simplă a stării - poziției pistonului cu senzor de câmp magnetic
- Fezabilitate mare - până la 5 milioane de cicluri de prindere statică
| Order-No. | Holding force |
Operating pressure min. |
Installation direction |
|---|---|---|---|
| [N] | [bar] | ||
| LBPS1501AS2-A | 400 [N] | 5.5 [bar] | from above |
| LBPS1501AS2-LP-A | 300 [N] | 4 [bar] | from above |
| LBPS1501SS2-A | 400 [N] | 5.5 [bar] | from the front |
| LBPS1501SS2-LP-A | 300 [N] | 4 [bar] | from the front |
| LBPS1502BS2-A | 400 [N] | 5.5 [bar] | from the front |
| LBPS1502BS2-LP-A | 300 [N] | 4 [bar] | from the front |
| LBPS1505AS2-A | 400 [N] | 5.5 [bar] | from the front |
| LBPS1505AS2-LP-A | 300 [N] | 4 [bar] | from the front |
| LBPS1505GS2-A | 400 [N] | 5.5 [bar] | from the front |
| LBPS1505GS2-LP-A | 300 [N] | 4 [bar] | from the front |
| LBPS2001AS2-A | 650 [N] | 5.5 [bar] | from above |
| LBPS2001AS2-LP-A | 450 [N] | 4 [bar] | from above |
| LBPS2001SS2-A | 650 [N] | 5.5 [bar] | from the front |
| LBPS2501AS2-A | 750 [N] | 5.5 [bar] | from above |
| LBPS2501AS2-LP-A | 550 [N] | 4 [bar] | from above |
| LBPS2501SS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2501SS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2502BS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS3001AS2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3001AS2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3001ES2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3001ES2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3001SS2-A | 1200 [N] | 5.5 [bar] | from the front |
| LBPS3001SS2-LP-A | 850 [N] | 4 [bar] | from the front |
| LBPS3002AS2-A | 1200 [N] | 5.5 [bar] | from the front |
| LBPS3501AS2-A | 1900 [N] | 5.5 [bar] | from above |
| LBPS3501AS2-LP-A | 1250 [N] | 4 [bar] | from above |
| LBPS3501ES2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3501ES2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3502AS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3502AS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3502BS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3502BS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS4501AS2-A | 2600 [N] | 5.5 [bar] | from above |
| LBPS4501AS2-LP-A | 1800 [N] | 4 [bar] | from above |
| LBPS4501ES2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4501ES2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4502AS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4502AS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4502BS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4502BS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS2002BS2-A | 650 [N] | 5.5 [bar] | from the front |
| LBPS2001SS2-LP-A | 450 [N] | 4 [bar] | from the front |
| LBPS2002BS2-LP-A | 450 [N] | 4 [bar] | from the front |
| LBPS2005AS2-A | 650 [N] | 5.5 [bar] | from the front |
| LBPS2005AS2-LP-A | 450 [N] | 4 [bar] | from the front |
| LBPS2012IS2-A | 650 [N] | 5.5 [bar] | from the front |
| LBPS2012IS2-LP-A | 450 [N] | 4 [bar] | from the front |
| LBPS2014DS2-A | 650 [N] | 5.5 [bar] | from the front |
| LBPS2014DS2-LP-A | 450 [N] | 4 [bar] | from the front |
| LBPS5501AS2-A | 3600 [N] | 5.5 [bar] | from above |
| LBPS5501AS2-LP-A | 2250 [N] | 4 [bar] | from above |
| LBPS5501ES2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5501ES2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS5502AS2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5502AS2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS2502DS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2504FS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2502BS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2502DS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2504FS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2505AS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2505AS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2505BS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2505BS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2512IS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2512IS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS2514DS2-A | 750 [N] | 5.5 [bar] | from the front |
| LBPS2514DS2-LP-A | 550 [N] | 4 [bar] | from the front |
| LBPS3005AS2-A | 1200 [N] | 5.5 [bar] | from the front |
| LBPS3003AS2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3004FS2-A | 1200 [N] | 5.5 [bar] | from the front |
| LBPS3002BS2-A | 1200 [N] | 5.5 [bar] | from the front |
| LBPS3002AS2-LP-A | 850 [N] | 4 [bar] | from the front |
| LBPS3002BS2-LP-A | 850 [N] | 4 [bar] | from the front |
| LBPS3003AS2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3004FS2-LP-A | 850 [N] | 4 [bar] | from the front |
| LBPS3005AS2-LP-A | 850 [N] | 4 [bar] | from the front |
| LBPS3010BS2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3010BS2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3012FS2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3012FS2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3014DS2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3014DS2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3014ES2-A | 1200 [N] | 5.5 [bar] | from above |
| LBPS3014ES2-LP-A | 850 [N] | 4 [bar] | from above |
| LBPS3503AS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3505AS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3505BS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3504FS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3503AS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3504FS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3505AS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3505BS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3510BS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3510BS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3512FS2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3512FS2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS3514ES2-A | 1900 [N] | 5.5 [bar] | from the front |
| LBPS3514ES2-LP-A | 1250 [N] | 4 [bar] | from the front |
| LBPS4504FS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4503AS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4505AS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4503AS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4504FS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4505AS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4505BS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4505BS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4510BS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4510BS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4512FS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4512FS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4514DS2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4514DS2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS4514ES2-A | 2600 [N] | 5.5 [bar] | from the front |
| LBPS4514ES2-LP-A | 1800 [N] | 4 [bar] | from the front |
| LBPS5502BS2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5502BS2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS5503AS2-A | 2900 [N] | 5.5 [bar] | from the front |
| LBPS5503AS2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS5505AS2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5505AS2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS5505BS2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5505BS2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS5512FS2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5512FS2-LP-A | 2250 [N] | 4 [bar] | from the front |
| LBPS5514ES2-A | 3600 [N] | 5.5 [bar] | from the front |
| LBPS5514ES2-LP-A | 2250 [N] | 4 [bar] | from the front |
